Key Roles and Benefits of Film Capacitors in Modern Motor Drive Systems

Film capacitors play a critical role in motor drive systems, ensuring voltage stability, reducing ripple currents, and suppressing electromagnetic interference. With their high reliability, long lifespan, and excellent high-frequency performance, film capacitors are increasingly indispensable in industrial drives, electric vehicles, and smart manufacturing systems.



Introduction to Film Capacitors



Film capacitors consist of a thin dielectric film coated with a metal layer. Common types include:

Metallized Polypropylene (MKP): High voltage and pulse tolerance, low ESR, low loss

Metallized Polyester (MKT): Cost-effective, suitable for moderate voltage applications

Safety-rated X/Y Capacitors: Designed for EMI suppression and compliance with global safety standards

Compared with electrolytic capacitors, film capacitors have no liquid electrolyte, making them highly reliable and long-lasting, even under harsh conditions



Applications in Motor Drive Systems



DC Bus Filtering (DC-Link)

Film capacitors smooth the DC bus voltage and store energy in variable-frequency drives (VFDs). Their low ESR and ESL help absorb high-frequency ripple from IGBT or MOSFET switching, protecting power devices and improving efficiency.

*Key Features: High ripple current capability, low loss, stable voltage



Snubber / Absorption Circuits

Voltage spikes from fast switching in inverters can damage power devices. Film capacitors with high dv/dt tolerance and pulse withstand capability are ideal for snubber or absorption circuits, ensuring stable operation.

*Applications: IGBT snubber, resonant circuits, overvoltage protection



EMI Filtering (Electromagnetic Interference Suppression)

Safety-rated X2 and Y2 film capacitors suppress conducted EMI in motor drives, ensuring compliance with EMC standards.

X Capacitors: Suppress differential-mode interference

Y Capacitors: Suppress common-mode interference

Advantages: Certified to UL, ENEC, CQC standards; low loss



Advantages of Film Capacitors



Feature	Benefit
High voltage & pulse withstand	Reliable under high-frequency PWM circuits
Long lifespan	No electrolyte; service life >100,000 hours
Low ESR/ESL	Reduces losses, improves energy efficiency
Stable in harsh conditions	Operates from –40°C to +105°C
Robust mechanical strength	Resistant to vibration and shock



Film capacitors provide high performance and reliability, making them ideal for applications where conventional electrolytic capacitors may fail.



Typical Motor Drive Applications



Application	Function	Capacitor Type	Key Feature
DC-Link Filtering	Smooth DC bus voltage	MKP series	Low ESR, high ripple withstand
Snubber/Absorption	Suppress voltage spikes	High-pulse MKP	Fast response, high dv/dt
EMI Filtering	Suppress EMI	Safety-rated X1/X2/Y2	Certified safety, low loss
Output Filtering	Smooth motor output	MKP series	Low loss, high-frequency stability



Example: A three-phase VFD may include a DC-Link capacitor bank, snubber/absorption capacitors near IGBT modules, and EMI suppression capacitors at the input. Proper selection enhances power density, reduces heat, and extends system lifespan.



UF Capacitors – Trusted Film Capacitor Solutions



At UF Capacitors, we offer reliable film capacitors for motor drive applications. Our MKP series provides stable DC-Link performance, while our snubber/absorption and X/Y safety-rated capacitors deliver robust protection and EMI suppression.



We design our capacitors using polypropylene thin-film dielectric with double-sided metallized electrodes, ensuring long life and stable operation across –40°C to +110°C. UF Capacitors aims to provide practical, high-quality solutions that can replace tier first brands to help our customers achieve reliable and efficient motor drive performance.



To learn more about our film capacitors and explore solutions for motor drive systems, please visit: www.ufcapacitors.com









Cross to:

Photo	Description	UF Series Code	Vishay SPRAGUE	Kemet	Faratronic
	Metallized Polyester Capacitors	CL21 Series	MKT368 Series MKT467 Series MKT468 Series	***	C21 Series
	Box Type Metallized Polyester Film Capacitor	CL21B Series	MKT371 Series MKT372 Series MKT373 Series MKT373M Series	R66 Series R60 Series F611 Series F612 Series	C23 Series
	Metallized Polypropylene Capacitor	CBB21 Series	***	***	C31 Series
	Box Type Metallized Polypropylene film Capacitor	CBB21B Series	MKP385（DC） Series KP1836（AC）Series	F461 Series F464 Series PMR-205 Series	C32（MKP21）Series
	High Voltage Metallized  Polypropylene Capacitor	CBB81 Series	***	***	C14 Series
	X2 Metallized Polypropylene Film Capacitor	X2 Series	MKP3382 Series MKP3384 Series MKP3392 Series	R46 Series PHE840M Series PHE850 Series PMR-209 Series	C42(E)MKP62 Series
