AI Server Drives Tantalum Capacitor Demand Surge: UFcapacitors Complete Series Solutions

In the era of AI computing power explosion, data centers are experiencing unprecedented upgrade pressure. While the industry discusses GPU computing power and HBM bandwidth, a small tantalum capacitor is quietly becoming a key player in the AI arms race at the power management level. This article delves into how AI servers drive the surge in tantalum capacitor demand and comprehensively introduces how UFcapacitors' solid tantalum capacitors (CA45/CA45U series) and polymer tantalum capacitors (CA55 series) provide complete power solutions for AI servers.





Technical Necessity: Why Are Tantalum Capacitors "Indispensable" for AI Servers?



AI chips (GPUs/TPUs) process massive amounts of data with extremely fast current changes, demanding stringent power supply stability. This requirement for high power density and transient current calls for capacitors with extremely low equivalent series resistance (ESR) and high stability.



Core Advantages of Tantalum Capacitors:



1. Ultra-Low ESR: Polymer tantalum capacitors can reduce ESR to 5-20mΩ, an order of magnitude lower than traditional tantalum capacitors, perfectly meeting the power integrity requirements of DC-DC converters and high-voltage systems.



2. High Ripple Current Capability: They can withstand higher ripple currents than liquid electrolytic capacitors, adapting to high-frequency power switching and fast pulse loads in AI servers.



3. Excellent Temperature Stability: Electrical performance varies minimally within the -55℃ to +125℃ range, ensuring stability during long-term full-load operation in data centers.



4. High Reliability: Solid polymer capacitors have no dry-out issues, offer good heat and vibration resistance, meeting the demands of 24/7 high-load AI data center operations.



5. Safety: No risk of "failure short circuit explosion"; the conductive polymer layer typically fails open-circuit under over-stress, improving overall system safety.



Key Role in SSD Power Loss Protection: In AI servers, polymer tantalum capacitors are used for enterprise SSD hold-up—releasing energy during power loss to enable DRAM to write data back to NAND flash.



Staggering Usage: AI Servers Are "Tantalum Hungry"



Specific Usage Data:



-Each NVIDIA H100 GPU chip uses approximately 37 tantalum capacitors.

-The GB200 system uses about 3,000 capacitors per unit.

-The next-generation GB300 rack will see usage jump to at least 5,000 capacitors, widely used in power boards, switches, and server motherboards.



ASIC Server Contribution: As major cloud service providers widely adopt tantalum capacitors in ASIC servers (such as TPU servers) to fully unleash computing power, per-unit usage even exceeds that of GPU servers. TPU chip shipments are expected to surge by 1 million units in 2026, a year-on-year increase of 42.1%, directly driving explosive growth in tantalum capacitor demand.



UFcapacitors Complete Product Matrix: Comprehensive Solutions for AI Servers



UFcapacitors' product line covers solid tantalum capacitors and polymer tantalum capacitors, providing complete power solutions for AI servers from power entry to chip core.



3.1 Polymer Tantalum Capacitor Series (CA55) — For Core Power Supply



Polymer tantalum capacitors use conductive polymer cathodes, featuring ultra-low ESR and high ripple current capability, making them ideal for GPU/TPU core power supply in AI servers.



CA55 Application Scenarios:



-GPU/TPU core power modules

-HBM high-bandwidth memory power supply

-VRM output mid-to-low frequency decoupling

-High-frequency DC-DC converter output



3.2 Solid Tantalum Capacitor Series (CA45/CA45U) — For Auxiliary and Peripheral Circuits



Solid tantalum capacitors use traditional manganese dioxide cathodes, featuring high reliability, long life, and low cost, suitable for non-core but equally important auxiliary circuits in AI servers. The CA45U is a low ESR series, suitable for applications with higher requirements for ESR.



CA45/CA45U Application Scenarios:



-Server Motherboard Auxiliary Power: Provides stable power for PCIe slots, fan controllers, etc. (CA45 standard)

-Management Controller Power Supply: BMC (Baseboard Management Controller) and other management units (CA45 standard)

-Signal/Power Filtering Sensitive to ESR: Suitable for circuits with higher requirements for ripple and noise (CA45U low ESR series)

-Backup Power Circuits: Real-time clock (RTC), configuration storage, etc. (both CA45 and CA45U)



3.3 Full Series Application Division: Each Plays Its Role, Working Together



In the complete power network of AI servers, UFcapacitors' three series each play their roles:

Application Level	Recommended Series	Core Task	Technical Advantage
Core Chip Power	CA55 Polymer	GPU/TPU/HBM Power	Ultra-low ESR, high ripple current
Board-Level Auxiliary Power	CA45 Standard	PCIe, DDR, Controllers	High reliability, long life
Low ESR Requirement Scenarios	CA45U Low ESR	Sensitive circuit filtering	Lower ESR than standard



UFcapacitors Full Series Alternative Solutions



UFcapacitors products serve as direct replacement solutions for first-tier international brands, offering customers more cost-effective options.



Photo	Description	UF Capacitors Series Code	AVX	Kemet	Vishay	Panasonic
	Polymer Tantalum Capacitors	CA55 Series	TCJ Series	T520 Series T521 Series	T55 Series	TQC Series TPB Series TPF Series TPG Series
	Tantalum Chip Capacitors, General Purpose, A,B,C,D,E Case	CA45 Series	TAJ Series F913 Series TLJ Series	T491 Series T490 Series T489 Series	293D Series	TE Series ECST Series
	Low ESR Chip Tantalum Capacitors, A,B,C,D,E Case	CA45U Series	TPS Series F93 Series	T494 Series T495 Series	593D Series 594D Series TR3 Series	TEL Series
	Radial Epoxy Dipped Tantalum Capacitor	CA42 Series	TAP Series	T350-T390 Series	199D Series 489D Series ETPW Series ETQW  Series	ECSF Series



If you are interested in the application of UFcapacitors' full series tantalum capacitors in AI servers, please visit www.ufcapacitors.com or email karin@ufcapacitors.com for more product information and sample support.
